Filtration Principles of Pneumatic and Hydraulic Systems: A Comparison Study


This article is the third part of the following three-part series of articles:

Filtration and Drying Principles in Pneumatic Systems

Filtration Principles in Hydraulic Systems

Filtration Principles of Pneumatic and Hydraulic Systems: A Comparison Study


The filtration principles of pneumatic and hydraulic systems were given in the previous articles. The third part of the three-part series of articles on filtration principles in fluid power systems attempts to make a comparison of the filtration principles, as given in Table 1. A comparative study of the filtration principles would bring out the essential similarities as well as differences in the filtration principles and would provide an overall view of the subject matter.

Table 1 | A comparison of the filtration principles in pneumatic and hydraulic systems

ParameterPneumaticsHydraulics
Medium of energy transferCompressed airOil
ContaminantsParticles, moisture, oil, +Particles, chemical contaminants, moisture, air, +
Effect of contaminantsAbrade surfaces
Corrode internal parts
Reduce functionality and service life of components
Abrade surfaces
Corrode internal parts
Reduce service life of oil
Cleanliness standardsISO8573ISO 11171 & ISO4406
NAS1638
SAE AS4059
Particle removalFiltersFilters, Magnets
Moisture removalDryers, FiltersVacuum dehydrator
Oil (air) removalCoalescing filters
Adsorption filters
Air bleeds
Diffuser (Baffle screen)
Filter typesGeneral purpose filters
Coalescing filters
Adsorption filters
Surface filters/ Depth filters
Cartridge type/ spin-on
Inline filters
In-tank filters
Filter mediaSintered bronze/ polyethylene
Borosilicate glass microfibres
Activated carbon
Wire mesh
Paper
Synthetic
Filter locationsIntake
Mainline
Service line
Suction side
Pressure side
Return-line
Offline
